V. OPERATING INFORMATION PRESSURE WASHING SYSTEM OPERATING – To operate the pressure washing system, 1
leave the engine running between 1000 and 1200 RPM. Turn the
4
parking brake on (see page 30). The rinse supply valve for the pressure washer (fig. 5.52, item 4) may remain open unless 3
operating the solution tank rinse system. Close it before you activate the rinse system (see page 53). Activate the pressure washing pump (fig. 5.52, item 2) with hydraulic valve (fig. 5.53) mounted next to the hydraulic gear pumps.
2
DO NOT operate the pressure washing system while any FIG 5.52
other system is engaged, i.e. solution pump, hydraulic tread adjust, hydrostatic drive, etc. DO NOT allow the pump to run dry. Spray pressure is indicated by the gauge mounted above the pressure pump (fig. 5.52, item 1). MAINTENANCE – Remove and inspect in-line filter (fig. 5.52, item 3) occasionally and clean it as required.
NOTE: For further information regarding operation and maintenance of the FIG 5.53
pressure washing system, refer to your HYPRO® pump’s owner’s manual.
