V. OPERATING INFORMATION Tank Shutoff Valves To shutoff either or both solution tank sumps, manually close either or both 1½” ball valve(s) located under each solution tank (fig. 5.32). Your sprayer may be equipped with optional 1½” electric tank shutoff valves (fig. 5.33, item 3). To operate the electric tank shutoff valves, locate the solution tank switches in the console. To open or close the left solution tank, depress the “OPEN” or “CLOSED” side of the left
FIG 5.32
switch (fig. 5.33, item 1). To open or close the right solution tank, depress the “OPEN” or “CLOSED” side of the right switch
2 1
(fig. 5.33, item 2). Utilize the tank shutoff valves when: 1 - you wish to draw solution from only one tank or the other; 2 - you are operating on unlevel ground such as a hillside or terrace and you don’t want solution to siphon from one tank to the other (fig. 5.34); or
3
3 - you operate the rinse system (see pages 51-53).
3
FIG 5.33
FIG 5.34
