V. OPERATING INFORMATION SPRAY SYSTEM The spraying system is a constantly-monitored and
continuously-adjusted
computer-controlled
system. The cab-mounted digital monitor receives
information from various inputs to help determine GPM (gallons per minute) and GPA (gallons per acre).
SPRAY SYSTEM OPERATION INSTRUCTIONS OPERATION
PAGE REFERENCE
1. Calibrate spraying system monitor.
67
2. Check contents and quantity in spray tank.
NOTE: Never attempt to operate the spray system without solution in the spray tank. Operating the spray system with no solution in the tank will cause severe damage and void the warranty. 3. Completely open the tank valves. 4. Start engine and maintain a relatively low engine RPM setting (1,000
44 27-28
RPM). Increase engine RPM slowly until full recommended operating RPM is reached.
5. If desired, activate the agitation system.
46
6. Turn on the solution pump switch.
41
7. Turn on main spray power.
42
8. Place individual boom solution valve switches to the “ON” position.
42
9. Slowly move the hydrostatic control lever forward to obtain the
29
desired ground speed.
10. Frequently observe the pressure gauge. When it drops to zero, or spray pattern deteriorates, shut off main spray power, solution pump, and agitation system until refilling solution.
41, 42, 41, 46, 45
