V. OPERATING INFORMATION Parking Brake The
brakes
are
controlled
by
charge
pressure. When the engine is shut off or if the charge pressure is below 150 PSI the brakes will become activated. To set the brakes while the engine is running, activate the switch located below the spray system monitor (fig. 5.2). Lift the RED switch cover as shown in figure 5.3B. To engage the brakes, flip the switch up to the “ON” position as shown in figure 5.3C. To release the brakes, close the RED cover and this in turn will flip the brake switch to the “OFF” FIG 5.2
position. Always return the brake switch to the “OFF” position before moving the sprayer.
Activating the brake switch while the machine
is
moving
is
potentially
hazardous to the operator and the sprayer.
A
B FIG 5.3
C
