VIII. SERVICE AND MAINTENANCE SPRAY SYSTEM Solution Pump REBUILDING - Refer to the solution pump handbook accompanying this operator’s manual.
Line strainer See page 82 for more information.
Spray Tips At the beginning of each season, or as required, remove a FIG 8.56
random sample of spray tip caps (fig. 8.57, item 3) and inspect the nozzle tips. If they are plugged or worn, clean or replace them.
1
2
Nozzle Diaphragms At the beginning of each spray season, remove nozzle body cap (fig. 8.57, item 1) and inspect the diaphragm for wear or fit (fig. 8.57, item 2). Replace if necessary. Refer to accompanying
3
manual containing nozzle information.
Calibration See pages 67-68, section six on spray system calibration. FIG 8.57
Storage See page 103 on cold weather storage of spray system.
FOAM MARKER SYSTEM Wet Tank To prevent system condensation from contaminating the engine air compressor, remove moisture from the wet tank daily by pulling on its drain cord (fig. 8.58).
Winter Storage See page 103 on cold weather storage of foamer system. FIG 8.58
