VII. SERVICE AND MAINTENANCE FILTERS CONTINUED

Suction Filter 1

Remove and install a new 10 Micron rated suction filter (fig. 7.24, item 3) at the end

of

the

first

50

hours

of

use;

subsequently, replace the filter every 250 hours, or once a year, whichever comes first.

Charge Pressure Filter

3

Remove and install a new 4 Micron rated charge pressure filter (fig. 7.24, item 2) at the end

of

the

first

50

hours

of

use;

subsequently, replace the filter every 250

2

hours, or once a year, whichever comes first.

Return Filter

FIG 7.24

Remove and install a new 25 Micron rated return filter (fig. 7.24, item 1) at the end of the first 50 hours of use; subsequently, replace the filter every 250 hours, or once a year, whichever comes first.

RETURN FILTER (25 MICRON)

CHARGE PRESSURE FILTER (4 MICRON) HYDRAULIC RESERVOIR

SUCTION FILTER (10 MICRON ONLY)

CHARGE PUMP HYDRO-STATIC PUMP

FIG 7.25 SERVICE AND MAINTENANCE CONTINUED
