VII. SERVICE AND MAINTENANCE FLUIDS CONTINUED
Air Conditioning TYPE - The cab on your detasseler is equipped with a R134A air conditioning system. RECHARGING - Recharge it only with R-134A refrigerant. If your air conditioning system is mistakenly charged with R-12 refrigerant, serious problems, such as compressor seizure, may result. Therefore, confirm refrigerant before recharging system. If you do not have the proper recharging equipment, it is FIG 7.16
recommended that you allow an independent service agent service your air conditioning system.
FLUID CAPACITIES AND TYPES Engine oil pan (including filter) ........................ 17 quarts SAE 15W-40 Engine oil dipstick, L-H mark ..........................2 quarts
FIG 7.17
Hydraulic oil reservoir ......................................25 gallons anti-wear hydraulic oil Torque Hub® oil level ....................................... approx. 16 oz. EP-90 or 85-140 Engine cooling system ....................................7 gallons ethylene glycol Fuel tanks (2) ...................................................40 gallons ea. No. 1 or 2 diesel
SERVICE AND MAINTENANCE CONTINUED
