VI. TRANSPORTING TRAILERING CONTINUED
NOTE:
NOTE:
Be sure to read and understand the trailer’s
Extra care should be taken when loading the
owner and operator manual. Hitch the trailer
detasseler onto any trailer. Consider whether
to the pulling vehicle as shown in the trailer’s
it is best to back the detasseler on or drive
owner and operator manual.
the detasseler forward.
TOWING NOTE: It is not recommended that the detasseler be towed, but if it should ever be necessary, follow these steps carefully:
1. Fold the outriggers in and lock them to the detas seler. 2. Disengage Torque Hubs® by removing the two outer cap bolts, reversing the cap, and replacing the bolts. This process pushes on a spring-loaded splined shaft, disengaging the Torque Hub®. Failure to do this may damage the hub or brakes.
FIG 6.6
(fig.6.6)
NOTE: Wheel motors will be damaged if these steps are not taken.
When re-engaging Torque Hubs®, make sure the spring loaded splined shaft has returned to its expended position.
77
TRANSPORTING CONTINUED
