V. OPERATING INFORMATION LIGHTS WORK LIGHTS – The front of the canopy or optional cab houses four halogen work lamps (fig. 5.74 and 5.75) and the rear houses two halogen work lamps (fig. 5.72 and 5.73). Locate the light switch on the console panel (fig. 5.70). Pulling the switch out to the first “ON” position (fig. 5.71, item 2) will activate all available lights. Pulling the switch out to the second “ON” position (fig. 5.71, item 3) will deactivate the two outer front lights in addition to the two rear work lights. FIG 5.70
The ignition key does not have to be on in order to operate any of the working lights, but extended use without the engine operating to charge the battery is not recommended.
1
2
3
FIG 5.71
FIG 5.74
FIG 5.75 FIG 5.73
FIG 5.72
67 OPERATING INFORMATION CONTINUED
