V. OPERATING INFORMATION HAGIE TASSELTROL® CONTINUED
“ALL UP” and “ALL HOLD” Function This function can be used to raise or lower all row units at the same time. The switches to control this option are located on the hydrostat control handle (5.52). All the row units will move up when the red switch (5.52, item 1) is activated and will lower when the green switch (5.52, item 2) is activated. The parameters for dwell on the up move can be set to 0, 5, 10, 15, 20, or 25 seconds. The heads will move
FIG 5.52
up this amount of time without having to hold the red ON
switch in (only in values greater than 0). All heads will
AUTO
hold this position when the parameter is reached. To reOFF
sume automatic depth control, activate the green switch.
MAN.
DEPTH CONTROL
To program the ALL– UP and ALL– HOLD functions see pages 47 and 58.
LIFT
LIFT LIFT
LIFT LIFT
LIFT
1
2
4
6
3
5
Additional Features To temporarily lock a lift up, hold the up button for that lift while switching from the manual to auto mode. The display will show an “L” for that lift to indicate that it is locked and will not move down automatically. The lift will return back to normal operation when the manual mode is again
TASSELTROL / LS SYSTEM 12
selected. (fig. 5.54 A) To display the supply voltage and current for the controller, press the ALL-UP button while in the manual mode.
FIG 5.53
(fig. 5.54 B)
1
2
3
4
5
6
1
2
3
4
5
6
FIG 5.54 OPERATING INFORMATION CONTINUED
