V. OPERATING INFORMATION HAGIE TASSELTROL® CONTINUED
TASSELTROL® BOTTOM PARAMETER The bottom parameter is used to adjust the sensitivity of the bottom photocell. The bottom pho-
tom photocells, decrease the parameter toward B1. Generally this parameter can be left at B1.
tocell stops the down motion when its light is
To display the bottom parameter, select AUTO
blocked by corn. How much corn it has to see be-
and turn the control box power on. Wait three sec-
fore stopping the down move can be changed by
onds for the SELECT MANUAL message. Press
selecting one of the four values B1, B2, B3, or B4.
the UP button under PAR. Now press the UP but-
With B1 selected the down move will stop as soon
ton under the B value.
as corn is detected. With B4 selected the down
1. The active value of the parameter is indicated
move will continue a little longer. The normal or
by it blinking on and off, while the other three
default value for this parameter is B1, but can be
choices are displayed continuously.
set to any desired value. If the pullers run too shallow after moving down
2. To select a new value for the parameter, press the UP button under the desired choice.
into shorter corn, increase the parameter toward
3. After selecting one of the four choices, press
B4. If the pullers move too deep when going into
the LIFT 1 down button to escape this parame-
shorter corn or oscillate between the top and bot-
ter. 4. To save new values and escape the parameter mode, press the LIFT 1 down button a second time.
NOTE: FIG 5.47
See page 59 for more information regarding the LS photolights.
PHOTOCELLS BOTTOM PARAMETER SET TO B1 TOP BOTTOM
BOTTOM PARAMETER SET TO B4
