V. OPERATING INFORMATION HAGIE TASSELTROL® CONTINUED
SETTING UP THE HAGIE TASSELTROL®/LS SYSTEM 12™ LS System 12™ Parameters
FIG 5.43 Once you have set the operating parameters you can adjust the response parameters. These parameters are used to adjust the response of the controller and SELDOM need changing. The parameter values are stored in flash memory and will be retained even when no battery power is present. Your programmable control box is factory preset with the following parame-
ON
AUTO
ter defaults: BOTTOM PARAMETER – B1 See page 54 to
MAN.
OFF
DEPTH CONTROL
reprogram the bottom parameter. RESPONSE PARAMETER – R2 See page 52 to reprogram the response parameter. TOP PARAMETER – T3 See page 53 to repro-
LIFT
LIFT LIFT
LIFT LIFT
LIFT
1
2
4
6
3
FIG 5.44
5
gram the top parameter. These parameters will always be displayed until the control box is reprogrammed. Once reprogrammed, the new values for the parameters will appear in the window of the control box. To program the unit, first select the response parameter (page 52). If further adjustment is required for top and/or bottom parameters, see pages 53 and 54. OPERATING INFORMATION CONTINUED
