V. OPERATING INFORMATION HAGIE TASSELTROL® CONTINUED
7. Set the lift down speeds: (If you are not in parameter mode, do step one first and then do this one)
Press the LIFT 1 up button under the PAR on the LCD display screen six times and the display will show the current setting of the down speed for an
FIG. 5.41
auto move*, a manual move and an all– resume buttons. Now correct the fastest and slowest lifts to move with a value of 01 to 10. With the value set to 03 the lifts will move a little slower. This setting of 03 is useful for adjusting the
match the average speed by changing the offset value with the up/down buttons for that lift while in the DOWN OFFSET parameter. When finished set-
offset of the values for getting all the lifts the same ting the offset values, return the speed setting back speed. Typically these values are set to 05 for a to about 05. fairly fast speed. The values can be changed by
Now with all the lifts at their highest points, select
pressing the up and down buttons under the AUTO, AUTO so all the lifts will move down together. CorMAN or ALL (fig. 5.41). The values can be saved by pressing the LIFT 1
rect the values for any lifts that are not close to the speed of the others.
down button to exit this screen and save the new The values can be saved by pressing the LIFT 1 parameter setting. down button to exit this screen and save the new parameter setting.
8. Set the lift down offset: (if you are not in parameter mode, do step 1 first and then do this one)
Press the LIFT 1 up button under the PAR on the LCD screen seven times and the display will show the current setting of the down offset for the first three lifts (fig. 5.42). Pressing NEXT again will show the offset setting for the last three lifts.
FIG. 5.42
The down offset for each valve can be adjusted for a value from –19 to +20. The more positive the number the faster the lift will move. Typically the
NOTE:
offset is initially adjusted at a slightly slower speed
Once the parameters have been
by setting the lift down speed to 03.
set, very little adjustment will be
Exit the parameter mode and check the speed of
required.
each lift by moving it manually with the up/ down
