V. OPERATING INFORMATION Parking Brake
HYDROSTATIC SYSTEM CONTINUED
The
brakes
are
controlled
by
charge
pressure. When the engine is shut off or if the charge pressure is below 150 PSI the brakes will become activated. To set the brakes while the engine is running, activate the switch located on the right-hand switch panel (fig. 5.14 and 5.15).
FIG 5.14
Lift the RED switch cover as shown in figure 5.19A. To engage the brakes, flip the switch forward to the “ON” position as shown in figure 5.19B. To release the brakes, close the RED cover and this in turn will flip the brake switch to the “OFF” position as shown in figure 5.19C. Always return the brake switch to the “OFF” FIG 5.15
position before moving the detasseler.
FIG 5.16
FIG 5.18 FIG 5.17
A
B
C
FIG 519 OPERATING INFORMATION CONTINUED
