IV. PREPARING TO OPERATE ATTACHING LIFT ASSEMBLIES 2
OR 5
1
1
3
4
FIG 4.13 Refer to the Hagie 204 Parts Manual for cor-
3. Attach the lift arms (fig. 4.13, item 1) to the
rect hardware when following these steps:
toolbar mounting bracket (fig 4.13, item 5).
1. Attach the hoist column adapters (fig. 4.13,
4. Attach the lift arm cylinders to the lift arm as-
item 2) to the tool bar and outriggers at the
semblies (fig. 4.13, item 3).
appropriate spacing. Refer to the Hagie 204
5. Attach the tool bar weldment to the lift arm
Parts Manual for more information on spac-
assemblies (fig. 4.13, item 4).
ing.
6. Connect hydraulic hoses to lift cylinders. Re-
2. Attach the toolbar mounting bracket (fig. 4.13,
fer to the Hagie 204 Parts Manual for correct
item 5) to the hoist column adapters.
hydraulic schematics.
28
PREPARING TO OPERATE CONTINUED
