Series 90 Axial Piston Pumps Technical Information Technical specifications FLUID SPECIFICATIONS
Viscosity mm²/sec (cSt) [SUS] Minimum Continuous
7 [49] 12-80 [70-370]
Maximum
1600 [7500]
Temperature °C [°F] Minimum
-40 [-40]
Continuous Maximum
104 [220] 115 [240]
Filtration
250 - 114
Cleanliness Efficiency (suction filtration)
18/13 or better per ISO 4406 β35-45=75 (β10≥2)
Efficiency (charge filtration) Recommended inlet screen size
β15-20=75 (β10≥10) 100-125 μm [0.0039-0.0049 in]
520L0603 • Rev FB • July 2007
9
