IV. PREPARING TO OPERATE WHEEL TREAD AND ROW SPACING
Know the row spacing of the field you intend to detassel and A
follow the steps below to properly obtain the desired tread setting.
A
1. To adjust the tread width in or out, park the detasseler on level ground and shut off the engine.
NOTE: Dimension A (fig. 4.1) must be equal (see page 87) and steering pivot must be in vertical position (fig. 4.2, item 1). FIG 4.1 2. Loosen tie rod bolts (fig 4.2, item 2) and tie rod jam nuts (fig. 4.2, item 3). Remove the bolts and nuts from the tie rod.
1 3
3 2
2
FIG 4.2 PREPARING TO OPERATE CONTINUED
