VII. SERVICE AND MAINTENANCE TOE-IN ADJUSTMENT 1. Adjust
Hydra-Hug ®
suspension
until
5. Manually pry each front wheel in or out until
dimensions above and below steering arm are
each is lined up exactly with the corresponding
equal (fig. 7.61, dim. A — See page 87).
rear tire.
2. Turn steering wheel until center steering pivot
NOTE:
(fig. 7.62, item 1) is vertical.
A tight string placed across the face of the
3. Loosen tie rod jam nuts (fig. 7.62, item 5).
tires on each side will help line them up.
4. Remove tie rod bolts (fig. 7.62, item 3) on outer end of tie rod tube (fig. 7.62, item 2).
6. Turn inner tie rod (fig. 7.62, item 4) in or out until the bolt hole lines up with the bolt hole in the tie rod tube. Then turn one more full turn OUT.
A
7. Tighten jam nut. 8. Line up bolt holes on each side one at a time A
by turning the steering wheel one way or the other. Reinstall bolts and nuts as you line up each hole; tighten firmly. 9. Drive detasseler forward for approximately 100 yards as you cycle the steering back and forth repeatedly. Recheck toe-in (page 25) and FIG 7.61
readjust if necessary.
1 5
5 3
4
3
2
2
4
FIG 7.62 SERVICE AND MAINTENANCE CONTINUED
