Transport
1 Safety regulation for transportation
Accidents can happen when the paver and the screed are not properly prepared for transportation or when transportation is carried out improperly!
Reduce both the paver and the screed to their basic widths. Remove all protruding parts (such as the automatic leveling system, auger limit switches, aprons, etc.). When transporting under a special permit, secure these parts!
Close the hopper lids and engage the hopper transport safeguards. Lift the screed and engage the screed transport safeguards. Convert the protective roof (if equipped) and engage the latch.
Check that the clamping device for the auger crossbeam is fastened and that the telescopic tube cannot slide out (see chapter E, section 1.5).
Pack all parts that are not permanently fixed to the paver and the screed into the appropriate boxes and into the hopper. Close all coverings and check that they are securely seated.
When loading using ramps, there is a risk that the machine will slip, tilt or overturn. Drive carefully! Keep people away from the danger area! Additional stipulations for transportation on public roads:
Depending on local regulations, tracked propelled paver must not be driven as self-propelling vehicles on public roads. Note the different state and local regulations.
