D 3.0 Operation 1 Operating elements on the paver Operator’s platform
Seat console The seat console can pivot beyond the outer edge of the vehicle, providing the driver with a better view of the paving area in this position - Release the platform lock (1). - Swing the seat console to the desired position. - Engage the lock into one of the fixed positions (2).
After locking the seat console, check it to ensure it will not move into another position! Dust cover The dust cover (3) can be stored on the bar (4) behind the seat.
D 105
