93 ECM REPLACEMENT OPTION To save EMCP 3 GSC configuration data to an ECM Replacement file: Select from the Service Tool menu: SERVICE > COPY CONFIGURATION > ECM REPLACEMENT If there are no previously saved field replacement files, the following message is displayed: No Data Is Available. Load From ECM Now. Select which ECM’s configuration data is to be viewed and/or saved for future use. This configuration data to be saved in the ECM Replacement file is shown in FIGURE 43. NOTE: The option of deselecting certain setpoints can be chosen at this screen. After any selection changes are completed, the user must choose SAVE TO FILE. The ECM replacement file is now saved for future access. Make sure to note what directory and folder the file is stored at.
®
FIGURE 43: CATERPILLAR SERVICE TOOL ECM REPLACEMENT SCREEN
12 SAVING and Restoring Setpoints
