SCROLL DOWN
to: ENG COOL TEMP MON
If the setpoint is set to SENSOR then, to change Press ENTER KEY SCROLL DOWN
Press ESCAPE KEY
to: DATA LINK Press ENTER KEY and SCROLL DOWN
to: ENG OIL PRES MON
If the setpoint is set to SENSOR then, to change Press ENTER KEY SCROLL DOWN
to: choose DATA LINK, then Press ENTER KEY ®
PROGRAMMING USING CATERPILLAR SERVICE TOOL ®
To program the EMCP 3 sensors for Data Link input using the Caterpillar Service Tool as shown in FIGURE 19, do the following steps: ®
1. Connect to the EMCP 3 GSC using the Caterpillar Service Tool 2. Enter the Configuration Tool 3. Select Engine Coolant Temperature Monitor on the left 4. If the Engine Coolant Temperature Sensor Configuration is set to Sensor, change it to Data Link. 5. Select Engine Oil Pressure Monitor on the left 6. If the Engine Oil Pressure Sensor Configuration is set to Sensor, change it to Data Link.
9 ANALOG Inputs
