22 • •
Engine Oil Temperature Engine Fuel Temperature
ENGINE SCREEN 8 † • Fuel Pressure • Crankcase Pressure • Boost Pressure ENGINE SCREEN 9 † • Oil Filter Differential Pressure • Fuel Filter Differential Pressure ENGINE SCREEN 10 † • Air Filter Differential Pressure ENGINE SCREEN 11 † • Total Fuel Consumption • Instantaneous Fuel Consumption AC PARAMETERS AC OVERVIEW SCREEN • Average Line-Line AC Voltage • Average Current • AC Frequency • Power Factor (EMCP 3.2-3.3 only) • • •
Power Factor Lead/Lag status (EMCP 3.2-3.3 only) Total Generator Real Power – kW – (EMCP 3.2-3.3 only) Percent Real Power – as a percent of Generator Rated Power setpoint – (EMCP 3.23.3 only)
AC SCREEN 1 • Line-Line Voltages: A-B, B-C, C-A • Phase Currents: A, B, C • AC Frequency AC SCREEN 2 • Line-Neutral Voltages: A-N, B-N, C-N • Phase Currents: A, B, C (same as AC Screen 1) • AC Frequency (same as AC Screen 1) AC SCREEN 3 (EMCP 3.2-3.3 ONLY) • Per Phase Generator Real Power: A, B, C • Per Phase Generator Apparent Power: A, B, C • Per Phase Generator Reactive Power: A, B, C AC SCREEN 4 (EMCP 3.2-3.3 ONLY) • Per Phase Generator Real Power: A, B, C (same as AC Screen 3) • Per Phase Generator Apparent Power: A, B, C (same as AC Screen 3) †
Only shown if these parameters are supported by the engine ECM, and if the EMCP 3 setpoint Engine J1939 Support is set to Enhanced J1939.
4 INITIAL Operation and User Orientation
