TABLE 9 LED COLORS LED COLORS ROW 1 2 3 4 5 6
LED 1 Red Red Red Red Red Red
LED 2 Amber Amber Amber Amber Amber Amber
ROW 7 8 9 10 11 12
LED 1 Red Red Red Red Red Red
LED 2 Amber Amber Amber Amber Amber Amber
ROW 13 14 15 16
LED 1 Green Green Red Red
LED 2 Amber Amber Green Green
MODULE STATUS LED A red/green pair located at the bottom of the EMCP 3 GSC, is used to report Module/Network Status. The various states indicated are explained in Table 10 below. TABLE 10 ANNUNCIATOR MODULE / NETWORK STATUS LED BEHAVIOR BEHAVIOR Red solid
Green solid Green flashing
Red/Green flashing
EXPLANATION CAN data link diagnostic. For example: the module is wired wrong (Data Link), wrong cable, or no terminating resistor. CAN data link OK No CAN data link diagnostic, but no communication detected. Hooking the Annunciator up with the power on. No application software loaded
ANNUNCIATOR SOFTWARE CONFIGURATION ®
The Annunciator is field-programmable using the Caterpillar Service Tool. ® programmable to update software using the Caterpillar Service Tool.
It is also flash
The service tool software must be installed on a Windows PC. The Caterpillar communication adapter must be connected between the PC and the J1939 data link on which the target Annunciator is connected. (The service tool may be connected to the EMCP 3 GSC Accessory Data Link service connector). When connecting to the Annunciator, the user will first see the Module Summary screen shown in FIGURE 52.
