MAINTENANCE/ADJUSTMENTS
BRAKE CHECK Service specification Template Name: OM_1_col Template Date: 1994_04_29
Check .......................................................................................... Every 2000 hours (After the first 50 hours during the running-in period) STEP 4
STEP 1 Park the machine on flat, level ground and engage parking brake. STEP 2
TRIM THIS EDGE
CK99D004
Using the accelerator pedal, run the machine at maximum speed. STEP 5 CP99E003
Place the gear change lever in the second gear. STEP 3
Alt= to hide template information Alt+ to display template information
CK99D004
CP99D002
Place the direction of travel control lever in the fo rward position. Disengage parking brake.
Press down on the brake pedal. The machine should stop smoothly, in a straight line and the tension on the pedal should remain firm. If not, consult your CASE Dealer.
254
