MAINTENANCE/ADJUSTMENTS
Wheel nut torque settings Tool required
Template Name: OM_1_col Template Date: 1994_04_29
- A torque wrench
Service specifications Torque tightening check ................................................................ Every 250 hours Every day for five day, after remove a wheel (After the first 50 hours during the running-in period) Front wheel nuts ......................................................................................... 300 Nm Rear wheel nuts ..........................................................................................300 Nm
Replacing a wheel
STEP 7
Tools required - One 30 mm (1.18 inch) wrench for hexagonal head bolts STEP 1
TRIM THIS EDGE
Park the machine on flat, level ground, with no obstacles in the area. STEP 2 Loosen the retaining nuts from the wheel which is to be removed. STEP 3
Alt= to hide template information Alt+ to display template information
Start the engine and use the loader attachment and the stabilizers to lift the machine until the wheels are no longer in contact with the ground. STEP 4
CP99D004
In stall a new wheel, obse rving th e orientation of the tread pattern. STEP 8 Install the nuts and tighten them to correct torque, see “Wheel nut torque settings”. STEP 9
Stop the engine, engage parking brake and remove the starter switch key.
Remove the blocks from under the axle.
STEP 5
STEP 10
Place blocks under the axle for the wheel which is to be removed.
Lower the machine to the ground.
STEP 6 Remove the nuts and remove the wheel.
NOTE : Make sure that the new wheel has a sufficient inflation pressure. Reinflate it if necessary. IMPORTANT : Make sure you protect your face before using compressed air.
242
