OPERATING INSTRUCTIONS STEP 9
STEP 7
Template Name: OM_1_col Template Date: 1994_04_29
Lower the stabilizers. The rear wheels must be about 10 cm (4 inch). off the ground and the machine must be in a horizontal position. IMPORTANT : Whenever the backhoe attachment is used the machine must be resting on the stabilizers.
!
WARNING : Before operating the backhoe, ensure that no person is within its working range.
CD98G004
When using the extendable dipper (if equipped) make sure that the pin is placed in the external stowage bracket.
STEP 8
TRIM THIS EDGE
!
WARNING : Before starting work, make sure that no person is within the working range of the machine.
!
WARNING : Before starting work, check that all the backhoe controls operate correctly.
Alt= to hide template information Alt+ to display template information
CK98F035
CK97N041
Raise the boom. Pull the lever up to release the lock.
136
