OPERATING INSTRUCTIONS STEP 5 with
standard
loader
CK99E020
STEP 6 TRIM THIS EDGE
CD99E003
Start the engine. Place the loader bucket in the dumping position. Lower the bucket to the ground until the front wheels are about 10 cm (4 inch) above the ground.
Turn the seat round to the backhoe attachment position and adjust if necessary.
(Machine with 7 in 1 loader bucket)
Alt= to hide template information Alt+ to display template information
STEP 4 (Machine bucket)
CD99E004
Start the engine. Place the loader bucket in the level position. Lower the bucket to the ground until the front wheels are about 10 cm (4 inch) above the ground.
IMPORTANT : Normal engine speed when working is 1500-1800 rev/min. maximum. However, operate at a lower speed until operating skill develops. Switch to “Low flow” when working in very restricted conditions, particularly around underground cables or pipes and especially if other workers are in the vicinity. 1800 rev/min. should not be exceeded for backhoe work.
135
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
CK99E004
Accelerate and run the engine at the required speed.
