CONTROLS/INSTRUMENTS/ACCESSORIES
BACKHOE ATTACHMENT AUXILIARY HYDRAULIC TOOL CONTROLS (optional) Template Name: OM_1_col Template Date: 1994_04_29
For instructions on how to use these controls, see "Backhoe attachment auxiliary hydraulic tools" in the "Operating instructions" section.
Operating control pedal This pedal is located to the left of the backhoe control levers (with the operator’s seat in the backhoe attachment position) and enables auxiliary tools to be operated.
