CONTROLS/INSTRUMENTS/ACCESSORIES
After use, fold up the chock again and replace it in this housing.
WARNING : Whenever parking the machine on sloping ground, use the wheel chocks to immobilize the machine (specific to certain countries).
TOOLING The machine is supplied with the necessary tools for maintenance operations. These tools are located in the tool box : - 1 grease gun - 1 grease gun hose - 1 set of flat wrenches for hexagonal head bolts - 1 set of screwdrivers - 1 pair of pliers - 1 wrench for hexagonal socket head bolts - 2 pin drifts - 1 filter wrench - 1 hammer - 1 fuse tester - 1 coupler - 1 Allen key - 1 Hydraulic valve tool
115
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
!
CK98K005
Unfold the wheel chock and place the chock under a wheel.
Template Name: OM_1_col Template Date: 1994_04_29
CK98K004
The wheel chock is located on the righthand stabilizer (with the operator’s seat in the loader attachment position).
Alt= to hide template information Alt+ to display template information
WHEEL CHOCK (specific to certain countries)
