CONTROLS/INSTRUMENTS/ACCESSORIES
When installing the cap, make sure that it is correctly placed in the notches and lock it by turning clock-wise until it stops.
CK98F023
CK98F040
The sight glass shows the level of fluid in the reservoir. See "Hydraulic system" in the "Lubrication/Filters/Fluids" section.
NOTE : Clean around the filler cap before refilling.
Template Name: OM_1_col Template Date: 1994_04_29
IMPORTANT : Use a suitable hydraulic fluid. See "Fluids and lubricants" in the "Lubrication/Filters/Fluids" section.
TRIM THIS EDGE
Located in front of the engine, the capacity of the reservoir is 45 litres (12.4 US gals). To refill the reservoir, see "Hydraulic system" in the "Lubrication/Filters/Fluids" section.
Alt= to hide template information Alt+ to display template information
HYDRAULIC RESERVOIR
109
