3. Run the Conductive cable along the cable channel using all the cable clips.
4. Run the LVDS cable along the cable channel using all the cable clips.
5. Connect the LVDS cable to the Mainboard as shown.
6. Connect the Conductive cable to the Mainboard as shown.
Replacing the TouchPad Bracket IMPORTANT: The TouchPad cannot removed from the Upper Cover. Replace the entire Upper Cover if the TouchPad malfunctions. 1. Insert the TouchPad Bracket into the upper cover so the tabs slide into the securing slots in the upper cover.
110
Chapter 3
