Removing the Mainboard 1. See “Removing the Hinge Wells” on page 94. 2. Remove the single screw securing the Mainboard to the Lower Cover.
Step Mainboard
Size M2.5*3
Quantity
Screw Type
1
3. Pivot the Mainboard upward and remove it from the chassis, right side first. Place the Mainboard on a clean, dust-free surface.
Chapter 3
95
