Removing the Mainboard 1. See “Removing the Upper Cover” on page 67. 2. See “Removing the Modem Module” on page 79. 3. Remove the single securing screw.
Step Mainboard
Size M2.5*3
Quantity
Screw Type
1
4. Lift the mainboard right side first to remove it from the Lower Cover.
Chapter 3
81
