Chapter 5
Jumper and Connector Locations Top View VGA UMA
Discrete VGA
Item
Chapter 5
Description
Item
Description
PJP2
Battery Connector
JP13
Fan Connector
PJP3
AC-IN Connector
JLVDS1
LCD Connector
JP2
USB/B Connector
JRJ45
RJ45 Connector
JP3
FP/B Connector
JCRT1
CRT Connector
JP4
Bluetooth Connector
JUSB1
USB Connector
JP7
Touch Pad Connector
JUSB2
USB Connector
