13. Carefully pry open the LCD bezel and remove the bezel from the LCD module.
Removing the Inverter Board 1.
See “Removing the Battery Pack” on page 51.
2.
See “Removing the SD Dummy Card” on page 51.
3.
See “Removing the Express Dummy Card” on page 52.
4.
See “Removing the Lower Cover” on page 53.
5.
See “Removing the Fan Module” on page 60.
6.
See “Removing the CPU Heatsink Module” on page 61.
7.
See “Removing the CPU” on page 62.
8.
See “Removing the Middle Cover” on page 64.
9.
See “Removing the Keyboard” on page 65.
10. See “Removing the LCD Module” on page 66. 11. See “Removing the LCD Bezel” on page 82. 12. Remove the screw (H) that hold the board to the panel.
Chapter 3
Step
Size (Quantity)
Color
Torque
1
M2.5 x L5 (1)
Black
3 kgf-cm
83
