Removing the Middle Cover

1. See “Removing the Battery Pack” on page 51. 2. See “Removing the SD Dummy Card” on page 51. 3. See “Removing the Express Dummy Card” on page 52. 4. See “Removing the Lower Cover” on page 53. 5. See “Removing the Fan Module” on page 60. 6. See “Removing the CPU Heatsink Module” on page 61. 7. Open the LCD screen all the way to facilitate the easy removal of the middle cover. 8. Carefully insert the flat screwdriver under the side of the middle cover and gently pry up the middle cover.

9. Continue prying the middle cover until the full length of the cover releases from the main unit, then remove the cover.
