Screw List Screw
Part No.
A
M2 x L4
86.00G64.720
C
M2 x L3
86.9A552.3R0
D
M3 x L4
86.9A524.4R0
E
M2.5 x L6
86.00E33.736
G
M2 x L3
86.00C07.220
H
M2.5 x L5 (torque 1.6)
86.00F87.735
M2.5 x L5 (torque 3.0)
Removing the Fan Module
60
1.
See “Removing the Battery Pack” on page 51.
2.
See “Removing the SD Dummy Card” on page 51.
3.
See “Removing the Express Dummy Card” on page 52.
4.
See “Removing the Lower Cover” on page 53.
5.
Detach the heatsink cable.
6.
Detach the tin foil tape on the fan.
Chapter 3
