6.
Disconnect the two antenna cables from the WLAN board, then move the antennas away from the board.
7.
Remove the two screws (C) on the WLAN board to release the WLAN board.
8.
Step
Size (Quantity)
Color
Torque
1~2
M2 x L3 (2)
Silver
1.6 kgf-cm
Detach the WLAN board from the WLAN socket.
NOTE: When attaching the antennas back to the WLAN board, make sure the cable are routed properly.
Removing the Hard Disk Drive Module 1.
See “Removing the Battery Pack” on page 51.
2.
See “Removing the SD Dummy Card” on page 51.
3.
See “Removing the Express Dummy Card” on page 52.
4.
See “Removing the Lower Cover” on page 53.
