Closed Front View
#
Icon
Item
Description
1
Speakers
Left and right speakers deliver stereo audio output.
2
IEEE 1394 port (6-pin)
Connects to IEEE 1394 devices.
3
Infrared port
Interfaces with infrared devices (e.g., infrared printer and IRaware computer).
4
USB 2.0 port
Connects to USB 2.0 devices (e.g., USB mouse, USB camera).
5
Line-in jack
Accepts audio line-in devices (e.g., audio CD player, stereo walkman, mp3 player)
6
Microphone jack
Accepts inputs from external microphones.
7
Headphones/speaker/ line-out jack
Connects to audio line-out devices (e.g., speakers, headphones).
8
Bluetooth communication switch
Enable/disable the Bluetooth function. (manufacturing option).
9
Wireless communication switch
Enable/disable the wireless function. (manufacturing option).
10
Latch
Locks and releases the lid.
Chapter 1
5
