Jetta 2005 ➤ Body Repairs - Edition 04.2009
8.2
Installing
8.2.1
Preparing new part
Replacement part ♦ B-pillar reinforcement ♦ Front side member reinforcement ♦ Rear side member reinforcement ♦ Moulded foam element ♦ 2K body adhesive -D 180 KD3 A2-
rrectness of i t to the co nf o r m spec atio h re n in wit
es, in part or in w l purpos hole ercia , is n m m ot p o c erm or e t a itte iv r du rp o nl f e ng
ility ab y li an pt ce
AG. Volkswagen AG d agen oes ksw not l o gu yV b ara d e nte is r o eo h ut ra a c s s
thi sd o cu m en
ht rig py Co t.
agen lksw Vo by
AG.
Prote cted by c o py rig ht . C op yi
– Transfer parting cuts to the new parts and cut. Note
Use plug weld drill for “BTR steels” when drilling holes for SG plug weld seam . HSS drills are not suitable as they do not have the required durability. – Drill holes for SG plug weld seam. 8. Renewing B-pillar reinforcement
137
