Repair instructions
Group: 21 Short block 50. Alternator, sea water pump and engine mountings Install the alternator (1) and sea water pump (2). NOTE! There is a special nut for the lower, inner screw. Install the engine mounting with servo pump (3) on the mounting bracket in the order mentioned. Torque all the screws as specified in “Technical data.”
NOTE! Do not forget the spacers (4) on the engine mountings.
51. Drive belt/Alternator belt Apply a tool with a T60 Torx bit (1) to the cutout in the belt tensioner. Turn the belt tensioner (2) and insert a screwdriver (3) or similar into the hole which opens up and secure the belt tensioner. Install the drive belt (4) and then release the locking of the belt tensioner. NOTE! Make sure that the drive belt has not slid out of its grooves.
96
