Repair instructions
Group: 21 Short block 18. Cylinder head Put a new gasket (1) on the engine block. Make sure that a gasket of the correct thickness is used. This is indicated by a combination of holes (2) on the edge of the gasket, please refer to “Cylinder head gasket, measurement”.
19. Move no. 1 piston to Top Dead Center. Make sure that lock pin no. 9997005, for locking the crankshaft, bottoms against the block. Turn the crankshaft counter-clockwise until the crankshaft counterweight rests against the lock pin. No. 1 piston (1) is now about 2 mm before Top Dead Center. The crankshaft is now in the correct position, which can also be checked on the crankshaft’s toothed belt pulley (2) and the oil pump marking (3). Also refer to “Crankshaft, locking”.
84
