Installing, fixture
Installing, fixture Drained cooling system and engine oil. Engine removed. Special tools: 885510, 885815, 9986485
1.
1
Remove the expansion tank (1) by undoing its hose unions and through-going screws. Remove the servo system oil cooler (2) and coolant hose. Undo all remaining coolant hoses and remove the charge air pipe and hydraulic hose (3).
NOTE! Leave the short hose between the intercooler and the induction manifold in place. NOTE! Later, when the hydraulic hose bracket (4) is installed on the engine, Volvo Penta sealant part no. 840879-1 must be applied to the screw.
2.
Remove the turbocharger heat shield and air filter housing. Unscrew the exhaust bend and remove the gasket.
3.
Remove the turbocharger oil pipe (1). Plug all openings on the turbocharger (2) and the engine (3) with protective plugs 885510.
2
4
3
56
