Service work
Cam belt, change Removal 1. Apply a tool with a T60 Torx bit (1) to the cutout in the belt tensioner (2). Turn the belt tensioner and insert a screwdriver or similar into the hole (3) which opens up and secure the belt tensioner. Remove the drive belt (4).
50
2.
Undo the outer trimming gear cover screw (1) and the four hooks (2). Fold the top of the cover forwards and then lift the cover upwards.
3.
Use a socket (1) as a counterhold on the center nut. Then undo all the screws on the vibration damper (2).
