Service work
Flat Rate: 26215
Sea water pump, impeller, change Special tools: 3843948 Sea water drained
1.
Undo the outer hose and fold it to one side for better access. Unscrew the cover Remove the O-ring.
2.
Use tool no. 3843948 to pull the impeller out. IMPORTANT! Make sure that the inner edge of the housing is not damaged.
NOTE! On engines where the impeller does not have threads, prise the impeller out carefully with a pair of pliers.
3.
Grease (included in the renovation kit) the new impeller and O-ring. Insert the impeller on the pump shaft and install the cover together with the O-ring. Torque the screws to the specified values. Connect the hose. IMPORTANT! Check the inside of the cover. If there is any wear damage, it must be changed.
48
