Group: 22 Lubrication system
Design and function
Lubrication oil system The engines are provided with a complete pressure lubrication system. The lube oil pump is an internal gear pump with built-in safety valve, and is driven directly from the crankshaft. The oil filter is a replaceable filter element located in a housing. A bypass valve is located in the housing cover, in case the filter is blocked.
The pressure lubrication system supplies units such as the turbocharger, fuel pump, vacuum pump and the hydraulic units in the valve system with lubrication. The lube oil is cooled by a plate heat exchanger beside the sump.
1
3 2
14
4
13 5 12 6
11 10 1.
Coupling, high pressure pump
2.
Main oil duct
3.
Oil filter
4.
Crankcase ventilation, oil separator
5.
Oil pressure monitor
6.
Oil pump with safety valve
7.
Vent valve
8.
Inlet valve, piston cooling duct
9.
Oil cooler
10.
Pressure reduction valve
11.
Inlet pipe with strainer
12.
Piston cooling nozzles
13.
Inlet pipe to turbocharger
14.
Lubrication, vacuum pump
