Technical data
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21.
Battery Battery, main switch Starter motor Alternator Injector Inductive sensor, engine, rpm engine Pulse sensor-camshaft, rpm Pressure/Temperature sensor, charge air Oil pressure monitor, engine Temperature sensor, coolant Main relay Fuel pressure sensor, distribution pipe High pressure pump Starter relay Engine control unit – EDC15C11 Fuse, trim pump, 50 A Vacuum regulator Resistor, 33 Ohm Connector, 4-pin Accelerator butterfly, potentiometer Connector, engine control unit Stop button, engine room Blade fuse, EDC15, 20 A Blade fuse, EVC, 20 A Diode Connector, 6-pin Monitor, water in fuel
Blue Green Gray Light blue Light brown Red Black Violet White Yellow
Cable colors BL GN GR LBL LBN R SB VO W Y
174
22. 23. 24. 25. 26. 27.
Wiring diagram
