Group: 26 Cooling system
Repair instructions
Flat Rate: 26214
Sea water pump, seal, change Sea water pump removed Special tools: 885816, 9995919
1.
Unscrew the cover. Remove the O-ring and carefully prise the rubber impeller out, please refer to ”Sea water pump, impeller, change”. IMPORTANT! Make sure that the inner edge of the housing is not damaged.
2.
Fix the pump to a vice or similar. Put the hook on tool no. 9995919 under the seal (1) and pull it away. Remove the seal located closest to the bearing in the housing.
3.
Check the sea water pump bearing and the impeller housing. IMPORTANT! If any damage is discovered, which could cause leakage or rotation problems, the sea water pump must be changed.
4.
Installation Grease the new seal (1) with white Vaseline, part. no. 1161150 and put it on the shaft. Press the seal into place with mandrel no. 885816.
155
