Group: 23 Fuel system
Repair instructions
Fuel pressure sensor, change Cover removed 1.
Carefully clean the area on the engine around the fuel pressure sensor. IMPORTANT! Be very careful with cleanliness during the entire job. Be careful to ensure that no dirt particles get into the fuel system.
2.
Undo both the hoses for the sea water pump and fold them to one side. Undo the connector for the fuel pressure sensor (1). Fold the cables to one side. Unscrew the fuel pressure sensor.
3.
Install the fuel pressure sensor and torque it to 20 Nm. Install the sensor connectors and hoses on the sea water pump.
1 4.
Wipe up the fuel that has run out. Start the engine and check for leakage.
145
